Hardi HC 8500 User Manual

4 - System setup
4.92
Guidance Options
Save
This allows you can save a pattern (.AGSETUP file)
to the display's internal memory to the current
field.
Press and enter a unique pattern name.
When finished, press .
Pause
The Pause button allows your display to stop logging points along an AB Line. Once this button is pressed, a Resume button
will take its place until you press this button and Pause reappears.
÷
NOTE! If you are using the display to follow a set AB Line and wish to temporarily deviate from this line, you can use
the Pause button to pause the display's guidance logging activity. This feature could be used, for example, by a
vehicle operator who must refill a sprayer. When paused, the display will continue to give the distance back to the
original pause point position.
• Press button.
Press the Pause button on the Guidance screen. When you do so, the place where you paused appears on the Map
screen as a yellow ball.
÷
NOTE! You can pause a pattern even if you have not set the “B” point yet. If you do so, the message in the lightbar will
read "Need B." If you pause the pattern after you have set your AB Line, then the lightbar will indicate the distance
your vehicle must travel to return to the pause point.
• Press button.
To resume your pattern, press the Resume button to resume logging on your AB Line.
÷
NOTE! If you press the Resume button before you have returned to the original AB Line, your display will select the
closest AB Line to your vehicle.
Save
Save Pattern
Pause
Pause
Resume
