8.1
8 - Technical specifications
APPENDIX
Specifications
Technical Specifications
Do not exceed the specifications below:
• Storage Temperature: -4°F to +176°F (-20°C to +80°C)
• Operating Temperature: 14°F to +158°F (-10°C to +70°C)
• Operating Input Voltage: 9 –16 V DC
• Max Current Rating: 4.0 amp
• Environmental Protection Rating: IP64
• No Protective Grounding required
• Use 150V insulation rating for external circuits
±
WARNING! Exceeding these specifications may result in degraded operation and/or damage to the display.
Sprayer Offsets
Standard offsets for common HARDI® sprayers:
ATTENTION! For exact measurements, it is recommended to measure the specific sprayer/boom combination used.
Rear axle to Application point Left/Right from Center line
PRESIDIO 2700 84 in 0.00 in
ALPHA 4100 89 in 0.00 in
SARITOR 4000 84 in 0.00 in
SARITOR 5000 84 in 0.00 in
Hitch to Axle Hitch to Application Point
(Forward/Backward from Hitch)
Left/Right from Center line
RANGER 2000 150 in 204 in 0.00 in
COMMANDER 4500 209 in 307 in 0.00 in
COMMANDER 5500 238 in 339 in 0.00 in
COMMANDER 7000 238 in 339 in 0.00 in
NAVIGATOR 3000 180 in 266 in 0.00 in
NAVIGATOR 3500 180 in 266 in 0.00 in
NAVIGATOR 4000 180 in 266 in 0.00 in
NAVIGATOR 4000 (120’ SPC) 208 in 284 in 0.00 in
NAVIGATOR 6000 215 in 289 in 0.00 in
