7 - Fault finding
7.5
ISOBUS Modules
Modules not found
Configuration cannot be loaded due to the
missing HARDI® C2C Module.
Display is not detecting module.
Check that:
• Implement is connected to the tractor or that
the JobCom has power and is powered On.
• Check that the “Enable Task Controller” is
enabled in the ISOBUS Settings menu. Refer
to “ISOBUS Settings” on page 4.67.
Some Modules Not found:
Configuration can be loaded but is not
detecting all the modules associated with the
configuration. When loaded, it will not perform the
functions of the missing modules.
Display is detecting module.
Display is not detecting module.
An example of an application configuration is
shown. The HARDI® C2C Module is detected by the
display but the Norac UC5 Module are not.
It is possible to start a “Field Operation” but the
AutoTerrain/AutoHeight/AutoSlant will not be
functional.
All Modules Detected - Not all Modules are the
same as previously used
Configuration has a module that was not used
previously.
Module is not the one that was previously
used.
Field Operation Wizard: Operating Configuration Selection
JD 4630, Hardi Commander
Equipment Name
Vehicle
Implement
JD 4630
Hardi Commander
Device Hardi
Hardi C2C Module: Not found
Container
Device
Main Tank
Boom Control
Norac UC5 Module: Not found
Field Operation Wizard: Operating Configuration Selection
JD 4630, Hardi Commander
Equipment Name
Vehicle
Implement
JD 4630
Hardi Commander
Device Hardi
Hardi C2C Module
Container
Device
Main Tank
Boom Control
Norac UC5 Module: Not found
Field Operation Wizard: Operating Configuration Selection
JD 4630, Hardi Commander
Equipment Name
Vehicle
Implement
JD 4630
Hardi Commander
Device Hardi
Hardi C2C Module
Container
Device
Main Tank
Boom Control
Norac UC5 Module: Serial number does not match expected
