3 - Description
3.4
Screen Icon Conventions
The following control buttons are made available for entering names and calibration values into the system.
An on-screen Keyboard is made available when
appropriate for use during all setup processes.
Press the button to access the on-screen text
entry screen.
An on-screen Numeric Keypad is made available
for changing configuration settings and
calibration numbers. Press the button to access
the on-screen numeric entry screen.
An on-screen calendar is made available for
changing dates. Press the button to access the
calendar screen.
Symbols
Monday Tuesday Friday
Wednesday Thursday
Saturday Sunday
Monday
March 2015
Start Date
