MAINTENANCE
7-26
Clean Suction Filter--- when changing hydraulic
oil
The suction filter (2) is located on the bottom side in the
hydraulic oil tank. Clean the suction filter (2) when
changing hydraulic oil.
1. After draining hydraulic oil, remove suction filter (2)
together with cover (1).
2. Clean the hydraulic oil tank interior and the suction
filter (2).
3. Install suction filter (2) together with cover (1) to the
hydraulic oil tank.
4. Bleed air from the hydraulic system.
. (Refer to
“Bleed Air from Hydraulic System.”)
Wrench Size : 17 mm
Tightening Torque: 49 N⋅m (5 kgf⋅m, 36 lbf⋅ft)
M503-07-027
1
2
To Next Page
