MAINTENANCE
7-58
Check and Replace Seat Belt
Check --- daily
Replace --- every 3 years
Prior to operating the machine, thoroughly examine belt
(1), buckle (2) and attaching hardware (3). If any item is
damaged or materially worn, replace the damaged or
worn item(s) before operating the machine.
Replace seat belt (1) every three years regardless of its
apparent condition.
Check Bucket Hook (Optional) --- daily
Perform lifting work only after checking hook (1) for wear,
cracks, and deformations, the hook joint for cracks, and
rope guide (2) (latch, spring, pin, and spring pin) for
damage and malfunction.
M1MS-07-026
M107-07-129
２
１
Hoo
Spring
Spring Pin
Latch
Pin
2
1
3
To Next Page
