MAINTENANCE
7-35
Check Water Separator
--- daily
When water is accumulated in water separator (2),
loosen transparent filter case to drain water and
sediment.
Drain Fuel Tank Sump --- as required
Park the machine on a solid level surface. Loosen bolts
(5) to remove drain valve cover (6) from right-front under
cover (7). Rotate drain valve cover (6) to open the
checking port. Open drain valve (1) on the bottom of the
fuel tank and allow the water and sediments to drain
from the fuel tank sump.
M1MS-07-017
M1MS-07-018
M1MS-07-019
2
7
5
6
1
To Next Page
