Hitron CGN3 User’s Guide
3.5 The DOCSIS Event Screen
Use this screen to discover information about:
The nature of the upstream and downstream connection between the CGN3 and
the device to which it is connected through the CABLE interface.
IP details of the CGN3’s WAN connection.
Click Status > DOCSIS Event. The following screen displays.
Figure 15: The Status: DOCSIS Event Screen
Signal Strength
(dBmV)
This displays the power of the signal of each upstream
data channel to which the CGN3 is connected, in dBmV
(decibels above/below 1 millivolt).
Signal Noise Ratio
(dB)
This displays the Signal to Noise Ratio (SNR) of each
upstream data channel to which the CGN3 is
connected, in dB (decibels).
Channel ID This displays the ID number of each channel on which
the upstream signal is transmitted.
Table 12: The Status: DOCSIS WAN Screen (continued)
