126
MAINTENANCE
If the fuse is blown, check the
cause, then replace the fuse with a
spare fuse of the same rated
capacity. Unless the cause is found,
the fuse may blow again.
<Replacement>
1. Stop the engine, then disconnect
the battery cable.
2. Remove the engine cover.
3. Remove the fuse case lid and pull
the old fuse out of the clip with the
fuse puller.
4. Push a new fuse into the clips.
DESIGNATED FUSE:
10 A, 15 A, 30 A
If the propeller is damaged by
striking a rock, or other obstacle,
replace the propeller as follows.
• Before replacing the propeller,
remove the emergency stop
switch clip from the emergency
stop switch to prevent any
possibility of the engine being
started while you are working
with the propeller.
• The propeller blades may have
sharp edges, so wear heavy
gloves to protect your hands.
Propeller
PROPELLER
COTTER PIN
THRUST WASHER
CASTLE NUT
SPECIAL WASHER
PLAIN WASHER
COTTER
PIN
