41
5. INSTALLATION
Improperly installed outboard
motor can result in the outboard
motor dropped into the water, boat
not able to cruise straight ahead,
engine speed not increase, and
much fuel consumption.
We recommend that the outboard
motor be installed by your outboard
motor dealer.
Consult your dealer in your area for
the Y-OP (User Optional Parts)/
equipments installation and
operation.
Applicable Boat
Select the boat suitable for the engine
power.
Engine power:
BF40D: 29.4 kW (40 PS)
BF50D: 36.8 kW (50 PS)
Power recommendation is indicated
on most of the boats.
Do not exceed the boat
manufacturer’s power
recommendation. Damage and
injury may result.
Transom Height
Select the outboard motor which is
correct for the boat transom height of
your boat.
Type: T (Outboard Motor
Transom Height)
<when transom angle
is 12°>
S: 416 mm (16.4 in)
L: 521 mm (20.5 in)
Y: 556 mm (21.9 in)
X: 622 mm (24.5 in)
T
