134
STORAGE
3. Fill the battery with distilled water
to the upper level line. Never
overfill the battery.
4. Store the battery on a level surface
in a cool, dry, well ventilated place
out of direct sunlight.
5. Once a month, check the specific
gravity of the electrolyte and
recharge as required to prolong
battery life.
Outboard Motor Position
Transport and store the outboard
motor either vertically or
horizontally, as shown here. Attach
the stern bracket to stand and secure
the outboard motor with bolts and
nuts. Store the outboard motor in a
well-ventilated area free from direct
sunlight and humidity.
Vertical transport or storage:
Attach the stern bracket to a stand.
Horizontal transport or storage:
Rest the outboard motor on the case
protector.
Any other transport or storage
position may cause damage or oil
leakage.
UPPER
LEVEL
OUTBOARD MOTOR STAND
(starboard side turned down as shown.)
CASE PROTECTOR
