16. SPECIFICATIONS
MODEL BF40D
Description Code BBDJ
Type LHD LHTD
Overall length 794 mm (31.3 in)
Overall width 372 mm (14.6 in)
Overall height 1,364 mm (53.7 in)
Transom height
(when Transom
angle is 12°)
521 mm (20.5 in)
Dry mass
(weight)*
100 kg (220 lbs) 102 kg (225 lbs)
Rated power 29.4 kW (40 PS)
Full throttle range
5,000 – 6,000 min
-1
(rpm)
Engine type 4 stroke OHC in-line 3 cylinder
Displacement
808 cm
3
(49.3 cu-in)
Spark plug gap 0.6 – 0.7 mm (0.024 – 0.028 in)
Starter system Electric starter
Ignition system Full transistor battery
Lubrication
system
Trochoid pump pressure lubrication
Specified oil Engine: API standard (SG, SH, SJ) SAE 5W-30
Gear case: API standard (GL-4) SAE 90 Hypoid
gear oil
Oil capacity Engine: Without oil filter replacement
2.0 L (2.1 US qt, 1.8 Imp qt)
With oil filter replacement
2.1 L (2.2 US qt, 1.8 Imp qt)
Gear case: 0.41 L (0.43 US qt, 0.36 Imp qt)
D.C. output 12 V – 17 A
Cooling system Water cooling with thermostat
Exhaust system Water exhaust
Spark plugs DR7EB (NGK), X22 ESR-UB (DENSO)
Fuel pump Low pressure side: mechanical type
High pressure side: electrical type
Fuel Unleaded gasoline
(91 research octane, 86 pump octane, or higher)
Tank capacity 25 L (6.6 US gal, 5.5 Imp gal)
Gear change Dog type: Forward – Neutral – Reverse
Steering angle 35° right and left
Trim angle – 4° to 12° (when Transom angle is 12°)
Tilt up angle 63° (when Transom angle is 12°)
Transom angle 8°, 12°, 16°, 20°, 24°
Remote control
steering system
—
* Without battery cable, with propeller
Honda outboards are power rated in accordance with ISO8665 (propeller shaft output).
