36
CONTROLS AND FEATURES (Common)
Trim Tab
If the steering wheel/handle is pulled
to the side while running at full
speed, adjust the trim tab so that the
boat runs straight ahead.
Loosen the tightening bolt and turn
the trim tab right or left to adjust (see
page 91).
The anode metal is a sacrificed metal
which protects the outboard motor
from corrosion.
Do not paint the anode. It
deteriorates the function of the
anode metal, which can lead to rust
and corrosion damage to the
outboard motor.
TIGHTENING BOLT
TRIM TAB
PROPELLER
Anode
ANODE
(stern bracket)
ANODE
(each side)
