10-9
dummyheaddummyhead
STARTING SYSTEM
STARTER MOTOR REMOVAL/
INSTALLATION
Disconnect the starter motor wires from the starter
motor.
Remove the fan cover (page 5-2).
STARTER MOTOR
FLANGE BOLT
(GX270H: 8 x 40 mm,
GX390H1: 8 x 35 mm) (2)
STARTER MOTOR
STARTER MOTOR WIRE
TERMINAL WIRE
