14-11
dummyheaddummyhead
CRANKCASE
CLUTCH WEIGHT HOLDER Assy.
DISASSEMBLY/ASSEMBLY
Remove the clutch weight holder Assy. (page 14-9).
CLUTCH PRESSURE PLATE
CLUTCH WEIGHT HOLDER
CLUTCH WEIGHT CENTER
CLUTCH WEIGHT (48)
CLUTCH FREE SPRING (4)
CLUTCH SPRING HOLDER (4)
62Z7B000.book 11 ページ ２０１２年９月２７日　木曜日　午前１０時２１分
