11-3
dummyheaddummyhead
OTHER ELECTRICAL
CONTROL BOX REMOVAL/
INSTALLATION
Disconnect the control box wires.
When installing, refer to the HARNESS AND TUBE
ROUTING (with circuit protector) (page 2-10).
CONTROL BOX
ENGINE WIRE HARNESS
FLANGE BOLT (6 x 12 mm) (2)
OIL LEVEL
SWITCH WIRE
CHARGE COIL CORD
STARTER MOTOR WIRE
TERMINAL WIRE
