14-26
dummyheaddummyhead
CRANKCASE
CRANKSHAFT BEARING
REPLACEMENT (FLYWHEEL SIDE)
CRANKSHAFT BEARING (6206)
Install the 16 mm special nut [1] tightening the flywheel
to protect the crankshaft threads.
Pull out the radial ball bearing [2] using a commercially
available bearing puller [3].
Drive a new bearing [4] until it is fully seated on the end
using the special tools and hydraulic press.
TOOLS:
GX270H (6206):
Attachment, 30 mm [5] 07746-0030300
Inner driver handle, 40 mm [6] 07746-0030100
GX390H1 (6207):
Attachment, 35 mm [5] 07746-0030400
Inner driver handle, 40 mm [6] 07746-0030100
