MAINTENANCE
SEDIMENT CUP CLEANING
Turn the fuel valve lever [1] to the OFF position.
Remove the following:
– Sediment cup [2]
– O-ring [3]
Clean the sediment cup with non-flammable solvent
and allow them to dry thoroughly.
Install a new O-ring and sediment cup.
Tighten the sediment cup to the specified torque.
Check the installation part of the sediment cup for any
sign of fuel leakage.
SPARK PLUG CHECK/ADJUSTMENT
Remove the spark plug cap, and then remove the spark
plug [1] using a spark plug wrench [2].
Gasoline is highly flammable and explosive. You
can be burned or seriously injured when handling
fuel.
• Keep heat, sparks, and flame away.
• Handle fuel only outdoors.
• Wipe up spills immediately.
TORQUE: 3.9 N·m (0.4 kgf·m, 2.9 lbf·ft)
If the engine has been running, the engine will be
very hot. Allow it to cool before proceeding.
