14-32
dummyheaddummyhead
CRANKCASE
GX270H COUNTERSHAFT/P.T.O.
SHAFT BEARING REPLACEMENT
(CRANKCASE COVER SIDE)
P.T.O. SHAFT BEARING (6204)
Remove the crankcase cover (page 14-4).
Drive out the radial ball bearing [1].
Drive a new bearing [2] until it is fully seated on the end
using the special tools.
TOOLS:
Attachment, 42 x 47 mm [3] 07746-0010300
Pilot, 20 mm [4] 07746-0040500
Driver handle [5] 07749-0010000
62Z7B000.book 32 ページ ２０１２年９月２７日 木曜日 午前１０時２１分
