Program Outputs [53]
Use this option to modify the programming of the outputs on the system. You can also
change the attributes of the outputs. The programmable options are:
Attributes Description
1 = Output Function Assign output type
2 = Output Mode 1 = Latch - requires valid code to reset
2 = Reflex - follows activation status of zones
3 = Pulse (1 - 3000 secs) - activates for programmed period
3 = Output Polarity 0 = POS – 12 V going to 0 V in activation
1 = NEG – 0 V going to 12 V in activation
4 = Diag. Recording Assigns output to be active during Diagnostic Test
5 = Descriptor Assigns a descriptor of up to 12 characters for each output
6 = Control 1 = Mode (0=OFF, 1=Toggle, 2=Trigger)
2 = Show Status (0=OFF, 1=ON)
7 = Output Groups Assign groups to the output
Note: Groups only appear if the Group option is enabled (refer to Groups [63.1]).
Table 6 Output Attributes
Selecting Outputs
RIO Outputs
When you enter the option the first output on the system is displayed with the output address
and function on the top line, and the polarity and assigned groups on the bottom line.
Use A or B to scroll through the outputs, or enter the address of a specific output.
Press ent to programme an output. The first programming attribute 1=Op Function is
displayed.
Control panel outputs
Outputs 1 and 2 on the control panel use addresses 1001 and 1002 respectively
Horn (3)
The horn output is labelled as Output 3 on the PCB. The horn output is fully programmable,
Address 99 -.
Keypad Outputs
The keypad outputs are fully programmable. The address of the keypad output is the keypad
address prefixed with a star, for example the output for keypad 16 is 16. The function of
keypad outputs default to Entry/Exit Horn.
