Print [24, Quick Menu 4] Galaxy Flex Installer Manual
54
Print [24, Quick Menu 4]
Note: A serial printer must be connected to the panel via a printer interface module.
Only information corresponding to the groups assigned to the user is printed.
Print Codes [24.1.1]
Prints user number and name, type and groups assigned.
Print Zones [24.1.2]
Prints address, function, group (if group mode is enabled), status, descriptor (if assigned),
status of the chime, omit and part attributes, the RIO voltage and the zone resistance in
ohms;
Print Log [24.1.3]
Prints all events in the log, starting with the most recent and working backwards.
Print All [24.1.4]
Prints codes, zones and log details respectively.
The required option is selected by pressing the appropriate key 1-4. The printing begins
immediately and can be aborted by pressing esc.
Access Doors [25]
Use this option to display the event log information relating to access control events. The
a
ccess event log can be filtered using the following options.
View All [25.1]
Use this option to display all events in the access log.
Note: If Access Mode has not been enabled (refer to Access Mode [69.1]) the message No
Entries is displayed on entering this option.
User [25.2]
Use this option to show all events for the selected user. Managers can see all the users.
Individual users can see their own events only.
Reader [25.3]
Use this option to show all events for a particular Access Reader. If there are no MAX/DCM
modules connected to the system the message None Detected is displayed. If there is more
than one device on the system press A or B to view the details of each device.
Additional function for MAX reader address display
MAX modules, unlike other peripherals, do not have rotary switches to set their addresses.
P
ressing # in this option displays the address on each module in binary format using LEDs.
To help you identify each of the MAX modules, the keypad displays a graphic
