Galaxy Flex Installer Manual Appendix C: SIA event structure
209
Appendix C: SIA event structure
Event
Type
SIA
Level
ACC.
Block
DATA Block Format
(N block code)
Ascii Block Format
(A block code)
Explanation
Zone 3,4 #xxxxxx Ntixx:xx/rixx/EVzzzz Aeeeeeeeeesiiiiiiii
dddddddddddddddd
Detector alarmed,
keyswitch etc
2 #xxxxxx Ntixx:xx/rixx/EVzzzz
1 #xxxxxx NEVzzzz
0 #xxxx NEVzzzz
User 3,4 #xxxxxx Ntixx:xx/rixx/iduuu/pixxx/EV Aeeeeeeeeesiiiiiiii
dddddd
User Set/Unset, reset,
duress, etc
2 #xxxxxx Ntixx:xx/rixx/iduuu/pixxx/EV
1 #xxxxxx NEVmmm
0 #xxxx NEVmmm
Module 3,4 #xxxxxx Ntixx:xx/rixx/pimmm/EV Aeeeeeeeeesiiiiiiii
ddd
1. With ri modifier:
Set with A or B key
without code
2. Without ri modifier:
Keypad added, Rio
missing etc
2 #xxxxxx Ntixx:xx/rixx/pimmm/EV
1 #xxxxxx NEVmmm
0 #xxxx NEVmmm
Event 3,4 #xxxxxx Ntixx:xx/rixx/EV Aeeeeeeeeesiiiiiiii 1. With ri modifier:
Automatic set, timer
activated
2. Without ri modifier:
Automatic test, engineer
mode
2 #xxxxxx Ntixx:xx/rixx/EV
1 #xxxxxx NEV
0 #xxxx NEV000
Key
Data Block
ti Time modifier
ri Group modifier (not used if groups are
disabled)
id User modifier
u User number
pi Peripheral modifier
m Peripheral number
EV Event Code Type (see SIA event list
supplied)
z Zone number
x maximum digits for modifier field
Ascii Block
e Log event (9 chars, see Log Event in table
supplied)
s Event state ('+' : ON, '-' : OFF, ' ' : NOT
USED)
I Site identifier (8 char description of site - can
be blank)
d Descriptor (additional text to describe event),
1. Zone Event - 16 character zone descriptor
2. User Event - 6 character user name
3. Module Event - 3 character module name,
'RIO' (8 zone module), 'KEY' (keypad), 'MAX'
(Proximity Reader), 'COM'
(COM1 = Int Telecom, COM4 = Ethernet,
COM5 = GSM/GPRS, COM6 = USB)
