116 Xenon XP User Guide
Working Orientation
Some barcodes are direction-sensitive. For example, KIX codes and OCR can
misread when scanned sideways or upside down. Use the working orientation
settings if your direction-sensitive codes will not usually be presented upright to
the scanner. Default = Upright.
* Video Reverse Off
Upright:
Vertical, Top to Bottom:
(Rotate CW 90°)
Ups ide Down:
Vertical, Bottom to Top:
(Rotate CCW 90°)
* Upright
Vertical, Bottom to Top
Upside Down
Vertical, Top to Bottom

Honeywell Xenon XP 1952g Specifications

General

Type	Handheld bar code reader
Sensor type	-
Scanner type	1D/2D
Pitch reading angle	-45 - 45 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	Code 128, Code 39, U.P.C.
Optical sensor resolution (W x H)	1240 x 800 pixels
2D (matrix & stacked) barcodes supported	Data Matrix, PDF417, QR Code
Battery life	14 h
Charging time	4.5 h
Battery capacity	2400 mAh
Power source type	Battery
Number of reads per charge	50000
Wireless range	10 m
Bluetooth version	4.2
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Product color	Black
LED indicators	Yes
Built-in display	No
Protection features	Bump resistant
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	99 mm
Width	64 mm
Height	165 mm
Weight	220 g
