Honeywell Xenon XP 1952g User Manual

198 Xenon XP User Guide
QR Code
< Default All QR Code Settings >
QR Code On/Off
This selection applies to both QR Code and Micro QR Code.
QR Code Message Length
Scan the barcodes below to change the message length. Refer to Message Length
Description (page 152) for additional information. Minimum and Maximum
lengths = 1-7089. Minimum Default = 1, Maximum Default = 7089.
QR Code Append
This function allows the scanner to append the data from several QR Code
barcodes together before transmitting them to the host computer. When the
scanner encounters an QR Code barcode with the append trigger character(s), it
buffers the number of QR Code barcodes determined by information encoded in
those barcodes. Once the proper number of codes is reached, the data is output in
the order specified in the barcodes. There are 3 ways to scan appended QR Code:
One Scan: Pull the trigger one time and all appended QR Codes in the same image
are decoded.
* On
Off
Minimum Message Length
Maximum Message Length

Honeywell Xenon XP 1952g Specifications

General

Type	Handheld bar code reader
Sensor type	-
Scanner type	1D/2D
Pitch reading angle	-45 - 45 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	Code 128, Code 39, U.P.C.
Optical sensor resolution (W x H)	1240 x 800 pixels
2D (matrix & stacked) barcodes supported	Data Matrix, PDF417, QR Code
Battery life	14 h
Charging time	4.5 h
Battery capacity	2400 mAh
Power source type	Battery
Number of reads per charge	50000
Wireless range	10 m
Bluetooth version	4.2
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Product color	Black
LED indicators	Yes
Built-in display	No
Protection features	Bump resistant
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	99 mm
Width	64 mm
Height	165 mm
Weight	220 g
