Honeywell Xenon XP 1952g User Manual

56 Xenon XP User Guide
Scanner Report
Scan the barcode below to generate a report for the connected scanners. The
report indicates the port, work group, scanner name, and address. To assign a
name to your scanner, refer to Menu Command Syntax, page 239.
Scanner Address
Scan the barcode below to determine the address of the scanner you are using.
Base or Access Point Address
Scan the barcode below to determine the address of the base or Access Point you
are using.
Scanner Modes
Your scanner is capable of working in single scanner mode, multiple scanner
mode, or with Bluetooth devices other than the charge base or Access Point.
Charge Only Mode
There may be times when you want to charge your scanner, but not link to the base.
For example, if a scanner is linked to an Access Point or other Bluetooth device and
you need to charge the scanner, but want to retain your existing link.
Scanner Report
Scanner Address
Base Address

Honeywell Xenon XP 1952g Specifications

General

Type	Handheld bar code reader
Sensor type	-
Scanner type	1D/2D
Pitch reading angle	-45 - 45 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	Code 128, Code 39, U.P.C.
Optical sensor resolution (W x H)	1240 x 800 pixels
2D (matrix & stacked) barcodes supported	Data Matrix, PDF417, QR Code
Battery life	14 h
Charging time	4.5 h
Battery capacity	2400 mAh
Power source type	Battery
Number of reads per charge	50000
Wireless range	10 m
Bluetooth version	4.2
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Product color	Black
LED indicators	Yes
Built-in display	No
Protection features	Bump resistant
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	99 mm
Width	64 mm
Height	165 mm
Weight	220 g
