109

NOTE:

In addition to the configuration on the access device, complete the following tasks:

• Configure the DHCP server so that the host can obtain an IP address on the segment of 192.168.1.0/24.

• Configure the web server so that users can log in to the web page to download 802.1X clients.

• Configure the authentication server to provide authentication, authorization, and accounting services.

Configuration procedure

1. Configure an IP address for each interface. (Details not shown)

2. Configure DHCP relay.

# Enable DHCP.

<Device> system-view

[Device] dhcp enable

# Configure a DHCP server for a DHCP server group.

[Device] dhcp relay server-group 1 ip 192.168.2.2

# Enable the relay agent VLAN interface 2.

[Device] interface vlan-interface 2

[Device-Vlan-interface2] dhcp select relay

# Correlate VLAN interface 2 to the DHCP server group.

[Device-Vlan-interface2] dhcp relay server-select 1

[Device-Vlan-interface2] quit

3. Configure a RADIUS scheme and an ISP domain.

For more information about configuration procedure, see the chapter “802.1X configuration.”

4. Configure 802.1X.

# Configure the free IP.

[Device] dot1x free-ip 192.168.2.0 24

# Configure the redirect URL for client software download.

[Device] dot1x url http://192.168.2.3

# Enable 802.1X globally.

[Device] dot1x

# Enable 802.1X on the port.

[Device] interface ethernet 1/0/1

[Device-Ethernet1/0/1] dot1x

Verifying the configuration

Use the display dot1x command to display the 802.1X configuration. After the host obtains an IP address

from a DHCP server, use the ping command from the host to ping an IP address on the network segment

specified by free IP.

C:\>ping 192.168.2.3

Pinging 192.168.2.3 with 32 bytes of data:

Reply from 192.168.2.3: bytes=32 time<1ms TTL=128
