To do… Use the command… Remarks
user view
quit
These three commands function in
the same way.
SFTP client configuration example
Network requirements
As shown in Figure 113 , an SSH connection is required between Switch A and Switch B. Switch A, an
SFTP client, needs to log in to Switch B for file management and file transfer. Use publickey authentication
and the RSA public key algorithm.
Figure 113 Network diagram
Configuration procedure
NOTE:
During SFTP server configuration, the client public key is required. Use the client software to generate RS
A
key pairs on the client before configuring the SFTP server.
1. Configure the SFTP client.
# Create VLAN-interface 1 and assign an IP address to it.
<SwitchA> system-view
[SwitchA] interface vlan-interface 1
[SwitchA-Vlan-interface1] ip address 192.168.0.2 255.255.255.0
[SwitchA-Vlan-interface1] quit
# Generate the RSA key pairs.
[SwitchA] public-key local create rsa
The range of public key size is (512 ~ 2048).
NOTES: If the key modulus is greater than 512,
It will take a few minutes.
Press CTRL+C to abort.
Input the bits of the modulus[default = 1024]:
Generating Keys...
++++++++
++++++++++++++
+++++
++++++++
# Export the host public key to file pubkey.
[SwitchA] public-key local export rsa ssh2 pubkey
[SwitchA] quit
Then, transmit the public key file to the server through FTP or TFTP.
