Technical Reference Guide C–7
Cable Pin-Outs
Accelerated Graphics Port (AGP Pro)
connector
Pins A1-A66 and B1-B66
pin signal A signal B pin signal A signal B
1
2
3
4
5
+12 V
TYPEDET#
Reserved
USB-
Ground
OVRCNT#
+ 5V
+ 5V
USB+
Ground
34
35
36
37
38
Vddq
AD22
AD20
Ground
AD18
Vddq
AD21
AD19
Ground
AD17
6
7
8
9
10
INTA#
RST#
GNT#
VCC1.5
ST1
INTB#
CLK
REQ#
VCC1.5
ST0
39
40
41
42
43
AD16
Vddq
FRAME#
Reserved
Ground
C/BE2#
Vddq
IRDY#
1.5VAux
Ground
11
12
13
14
15
Reserved
PIPE#
Ground
WBF#
SBA1
ST2
RBF#
Ground
Reserved
SBA0
44
45
46
47
48
Reserved
VCC 1.5
TRDY#
STOP#
PME#
Reserved
VCC 1.5
DEVSEL#
Vddq
PERR#
16
17
18
19
20
VCC 1.5
SBA3
SB_STB#
Ground
SBA5
VCC 1.5
SBA2
SB_STB
Ground
SBA4
49
50
51
52
53
Ground
PAR
AD15
Vddq
AD13
Ground
SERR#
C/BE1#
Vddq
AD14
21
22
23
24
25
SBA7
Reserved
Ground
Reserved
VCC 1.5
SBA6
Reserved
Ground
1.5 Vaux
VCC 1.5
54
55
56
57
58
AD11
Ground
AD9
C/BE0#
Vddq
AD12
Ground
AD10
AD8
Vddq
26
27
28
29
30
AD30
AD28
VCC 1.5
AD26
AD24
AD31
AD29
VCC 1.5
AD27
AD25
59
60
61
62
63
AD_STB0#
AD6
Ground
AD4
AD2
AD_STB0
AD7
Ground
AD5
AD3
31
32
33
Ground
AD_STB1#
C/BE3#
Ground
AD_STB1
AD23
64
65
66
Vddq
AD0
VREFGC
Vddq
AD1
VREFCG
A1
A2
B2
B1
A65
A66
B66
B65
E1
E2
F2
F1
E13
E14
F14
F13
C1
C2
D2
D1
C9
C10
D10
D9
