Technical Reference Guide 3–35
Installing or Replacing Parts
Install the Processor
1. Prepare the CPU socket:
a. If you are adding a second CPU, remove the plastic film covering the socket.
b. Verify that the CPU locking mechanism is in the unlocked position.
Verifying unlocked position
1
The special processor tool rotates this lock
2
Unlocked
3 Locked
