Technical Reference Guide 1–5
Product Information
Power Specifications
The power supply has Active Power Factor Correction (APFC) that meets EN61000-3-2 over the
range of 88-265 VAC rms.
Parameter Total Rating PCI Slots AGP Slots
Input voltage (wide-range) 100 – 127VAC
200 – 240VAC
Max input current
1
1. The worst case/highest current given the lowest input voltage and the maximum input power.
8.7A at 100VAC
4.4A at 200VAC
Input frequency 50 – 60 Hz
Max output power
2
2. Corresponds to the maximum DC power the power supply can provide to the system.
700W 6 slots available
at 15W/slot
Total of 90W
1 slot available
at 110W/slot
Max current at +12V -- combined 50A
Max current at +12V -- CPU0 15A
Max current +12V -- CPU1 15A
I/0 12V 15A
AGP 12V 15A
Max current at +3.3V 34A
Max current at +5V 25A
Max current at –12V 0.5A
Max current at +5V -- Standby 2A
