Technical Reference Guide 3–1
3
Installing or Replacing Parts
This chapter contains the following sections:
■ Locating System Components, page 3-1
■ Tools and Safety, page 3-5
■ Removing and Replacing Access Panels, page 3-6
■ Removing and Replacing Internal Components, page 3-8
Locating System Components
This section contains diagrams to help you locate system components. The diagrams in this
section include only the most frequently accessed components and connectors. For
comprehensive component and system board diagrams, see the label on the inside of the main
access panel.
■ Location of Internal Components, page 3-2
■ Exploded View of Main System Components, page 3-3
■ System Board Components and Connectors, page 3-4
For the location of items on the front and rear panel of the system, see:
■ Front Panel, page 1-7
■ Rear Panel, page 1-9
