C–10 Technical Reference Guide
Cable Pin-Outs
6-pin Power (Auxiliary)
No illustration is available.
Hard Drive Activity Connector
No illustration available.
connector position output awg wire color
P2
SSi--6-PIN
LENGTH=520
1V3P318ORANGE
2V3P318ORANGE
3V12-IO18YELLOW
4GROUND18 BLACK
5 GROUND18BLACK
6V12-IO18YELLOW
pin signal
1NC
2 PCIACT_L
3 PCIACT_L
4NC
