HP c8000 User Manual

Technical Reference Guide C–9
Cable Pin-Outs
24-pin Power (Main)
No illustration available.
connector position output awg wire color
P1
MAIN--24 PIN
LENGTH=520
1V3P318ORANGE
2V3P318ORANGE
3GROUND18BLACK
4V518 RED
5 GROUND18BLACK
6 V5 18 RED
7GROUND 18BLACK
8 PWR_OK 22 GRAY
95VSB18PURPLE
10 V12-IO 18 YELLOW
11 V12-IO 18 YELLOW
12 V3P3 18 ORANGE
13 V3P3 18 ORANGE
14 V12N 18 BLUE
15 GROUND 18 BLACK
16 PS_ON_L 22 GREEN
17 GROUND 18 BLACK
18 GROUND 18 BLACK
19 GROUND 18 BLACK
20 V3P3-RSENSE 22 BROWN
21 V5 18 RED
22 V5
V5-RSENSE
18
22
RED
RED
23 V5 18 RED
24 GROUND 18 BLACK
