Chapter 5 Accessories
29
when parts are short-circuited by metal objects such as tools or
jewelry. Disconnect telephone cables to avoid exposure to
shock hazard from telephone ringing voltages.
5. Remove the NetServer cover.
CAUTION Wear a wrist strap and use a static-dissipating work surface
connected to the chassis when handling components.
6. Remove the mass storage tray from one of the empty front shelves. Save
the screws for reuse.
7. If the CD-ROM is not an HP accessory, attach the mounting rails to the
CD-ROM with the screws provided.
8. Slide the drive completely into the shelf.
9. Connect the power and data cables to the rear of the drive (the connectors
are shaped to go in one way only). See “IDE Cabling” for more information
about which connectors to use.
10. Secure the drive in position using the screws removed from the mass
storage tray in step 6.
11. To allow access to the drive, remove the corresponding shelf filler panel
from inside the front bezel.
12. Replace the cover, external cables, and power cords.
Installing an IDE Hard Disk Drive In a Front Shelf
NOTE If your new hard disk drive already has a mounting tray
attached, you must remove it before you can install the drive
in your E Series NetServer.
