iLO-M.2-serial module componentsiLO-M.2-serial module components
ItemItem DescriptionDescription
1 Module stabilizer
2 iLO dedicated network port
3 Serial port cable connector
4 Standoff for the M.2 22110 SSD
5 Standoff for the M.2 2280 SSD
6 Standoff for the M.2 2242 SSD
7 M.2 slot
8 Serial port cable
9 Serial port cable clip
Not for use in this server
This M.2 slot supports a SATA or an NVMe SSD.
1
2
1
2
iLO-M.2-serial module components 142
