Drive power cablingDrive power cabling
4 LFF non-hot plug drive power cabling from the 4 LFF non-hot plug drive power cabling from the non-hot-plug power supplynon-hot-plug power supply
ColorColor DescriptionDescription
Orange P3 connector from the non-hot-plug power supply fan-out cable
Blue SATA-power splitter cable
4 LFF non-hot plug drive power cabling from the 4 LFF non-hot plug drive power cabling from the Flexible Slot power supplyFlexible Slot power supply
ColorColor DescriptionDescription
Orange Drive power cable (NHP PWR, from the Flexible Slot power fan-out cable )
Blue SATA-power splitter cable
