HP ProLiant ML30 Gen10 Plus User Manual

Installing the RPS enablement optionInstalling the RPS enablement option
PrerequisitesPrerequisites
Before you perform this procedure, make sure that you have a T-15 Torx screwdriver available.
ProcedureProcedure
1. Power down the server.
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Disconnect all peripheral cables from the server.
4. Do one of the following:
If the server is in tower mode, place the server on a flat, level surface with the access panel facing up.
If the server is in rack mode, remove the server from the rack .
5. Remove the access panel .
6. If installed, remove all media drives .
7. Disconnect all non-hot-plug power supply cables .
8. Remove the non-hot-plug power supply:
a. Remove the power supply screws (callout 1).
b. Press and hold the release latch (callout 2), and then remove the power supply (callout 3).
Installing the RPS enablement option 96

HP ProLiant ML30 Gen10 Plus Specifications

General

Processor Sockets	1
Memory	Up to 128 GB DDR4 ECC UDIMM
Memory Slots	4
Form Factor	Tower
Processor	Intel Xeon E-2300 series
Storage	Up to 4 LFF or 8 SFF drives
RAID Support	HPE Smart Array S100i, S100i SR Gen10 SW RAID
Network	1 x 1GbE
Power Supply	350W
Chipset	Intel C252
Storage Controller	HPE Smart Array S100i, S100i SR Gen10 SW RAID
Maximum Internal Storage	Up to 64 TB
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
Weight	Approx. 10.5 kg
