Step 3 Connect the other end of the power cable to the DC PDU in the cabinet.
The DC PDU is fastened horizontally in the rear of the cabinet. Connect the power cable to
the socket on the PDU according to the plan.
Step 4 Bundle the power cables to the cable guide using cable ties.
----End
7.2.6.9 Checking Cable Connections
Before checking cable connections, ensure that the power is cut off. Otherwise, any incorrect
connection or loose connection may cause human injury or device damage.
Table 7-3 Cable connection checklist
Item
Description
Power cable Power cables are correctly connected to the rear of the chassis.
Network cable Network cables are connected correctly to the management
port or service ports on the rear panel of the chassis.
Ground cable The server does not provide a separate ground port.
l In AC or HVDC environment, the power cables of AC
PSUs are grounded. Ensure that the power cables are in
good contact.
l In DC environment, the ground terminals of DC PSUs are
grounded. Ensure that the ground cables are in good
contact.
7.3 Power-On and Power-Off
7.3.1 Power-On Procedure
l Before powering on a server, ensure that the PSUs are switched off, all cables are
connected correctly, and the power supply voltage meets service requirements.
l During the power-on process, do not remove and insert drives or disconnect and connect
network cables or Console port cables.
l If a server is powered off, wait for at least one minute before powering it on again.
The server can be powered on in any of the following ways:
FusionServer Pro 2288H V5 Server
User Guide
7 Installation and Configuration
Issue 08 (2019-10-30) Copyright © Huawei Technologies Co., Ltd. 98
