3 Product Specifications
3.1 Technical Specifications
3.2 Environmental Specifications
3.3 Physical Specifications
3.1 Technical Specifications
Table 3-1 Technical specifications
Category
Specifications
Form factor 2U rack server
Chipset
Intel
®
C621/Intel
®
C622
Processors Supports one or two processors.
l Intel
®
Xeon
®
Scalable (Skylake and Cascade Lake)
processors
l Built-in memory controller and six memory channels
l Built-in PCIe controller, supporting PCIe 3.0 and 48 lanes
per processor
l Two UPI buses between processors, providing up to
10.4GT/s transmission per channel
l Up to 28 cores (2.7 GHz)
l Max. 3.8 GHz (four cores)
l Min. 1.375 MB L3 cache per core
l Max. 205 W TDP
NOTE
The preceding information is for reference only. Use the Intelligent
Computing Compatibility Checker to obtain specific information.
FusionServer Pro 2288H V5 Server
User Guide
3 Product Specifications
Issue 08 (2019-10-30) Copyright © Huawei Technologies Co., Ltd. 58

Huawei FusionServer Pro 2288H V5 Specifications

General

Form Factor	2U rack server
Processor	Intel Xeon Scalable processors
Max Processors	2
Memory	Up to 3 TB
Memory Type	DDR4
Operating Temperature	5°C to 40°C
Storage	Supports up to 12 x 3.5-inch drives
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Network	4 x GE ports
Power Supply	800W or 1600W PSU options
Dimensions (H x W x D)	86.1 mm x 447 mm x 748 mm
