Huawei FusionServer Pro 2288H V5 User Manual

Table 2-5 LOM port description
Chip Model Port Type Rate
Negotiation
Mode
Supported
Rate
Rates Not
Supported
X722 10GE optical
port
Auto-
negotiation
10000 Mbit/s
(full duplex)
10000M 10/100/1000M
10GE electrical
port
Auto-
negotiation
1000 Mbit/s
(full duplex)
1000M 10/100M
Auto-
negotiation
10000 Mbit/s
(full duplex)
10000M 10/100M
GE electrical
port
Auto-
negotiation
1000 Mbit/s
(full duplex)
1000M 10/100M
l Use Intelligent Computing Compatibility Checker to obtain information about the
cables and optical modules supported by the LOM ports.
l The LOM ports support NC-SI, WOL, and PXE.
l The LOM ports do not support forced rates.
l The electrical LOM ports cannot be connected to power over Ethernet (PoE) devices
(such as a switch with PoE enabled). Connecting a LOM port to a PoE device may
cause link communication failure or even damage the NIC.
l The electrical LOM ports do not support SR-IOV.
l Forcibly powering off a server will cause intermittent NC-SI disconnection and disable
the Wake on LAN (WOL) function of the LOM ports. To restore the NC-SI connection,
refresh the iBMC WebUI.
2.3 Processor
l The server supports one or two processors.
l If only one processor is required, install it in socket CPU1.
l The same model of processors must be used in a server.
l Contact your local Huawei sales representative or use the Intelligent Computing
Compatibility Checker to determine the components to be used.
FusionServer Pro 2288H V5 Server
User Guide
2 Hardware Description
Issue 08 (2019-10-30) Copyright © Huawei Technologies Co., Ltd. 19

Huawei FusionServer Pro 2288H V5 Specifications

General

Form Factor	2U rack server
Processor	Intel Xeon Scalable processors
Max Processors	2
Memory	Up to 3 TB
Memory Type	DDR4
Operating Temperature	5°C to 40°C
Storage	Supports up to 12 x 3.5-inch drives
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Network	4 x GE ports
Power Supply	800W or 1600W PSU options
Dimensions (H x W x D)	86.1 mm x 447 mm x 748 mm
