Huawei FusionServer Pro 2288H V5 User Manual

Figure 9-15 PuTTY Configuration
Step 6 Set Close window on exit to Only on clean exit.
Set Saved Sessions and click Save. You can double-click the saved record in Saved Sessions to log in to
the server next time.
Step 7 Click Open.
The PuTTY screen is displayed. Then the message "login as:" is displayed, prompting you to
enter a user name.
If this is your first login to the server, the PuTTY Security Alert dialog box is displayed. Click Yes to
proceed.
Step 8 Enter the user name and password.
If the login is successful, the server host name is displayed on the left of the prompt.
----End
9.5 Configuring VMD Settings
The Intel Volume Management Device (VMD) is a module integrated in the processor on the
Purley platform. It is used for surprise hot plug, management, and error processing of SSDs.
FusionServer Pro 2288H V5 Server
User Guide
9 Common Operations
Issue 08 (2019-10-30) Copyright © Huawei Technologies Co., Ltd. 134

Huawei FusionServer Pro 2288H V5 Specifications

General

Form Factor	2U rack server
Processor	Intel Xeon Scalable processors
Max Processors	2
Memory	Up to 3 TB
Memory Type	DDR4
Operating Temperature	5°C to 40°C
Storage	Supports up to 12 x 3.5-inch drives
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Network	4 x GE ports
Power Supply	800W or 1600W PSU options
Dimensions (H x W x D)	86.1 mm x 447 mm x 748 mm
