English - 115
7. MAINTENANCE AND SERVICE
the mower should also be charged at some time
during winter storage. You can then place the
mower in the charging station with the main switch
in the OFF position for a week.
The Automower should be stored, preferably in the
original packaging, in a dry area, standing on all
wheels. There is also a wall mount suitable for all
models, which is excellent for winter storage
(part no. 504 82 13-01).
The charging station, transformer and low voltage
cable should be kept indoors during the winter if
possible. It is then important to remember to protect
the ends of the boundary wire from moisture by placing
them, for example, in a tin with anhydrous grease. If
the charging station housing accessory (504 82 14-01)
is used, the charging station can be left outdoors for
the winter. However, the mower must always be stored
indoors.
7.3 Regreasing
The chassis halves of the mower must be regreased,
where necessary, each time the chassis is opened. In
addition, regrease at least once every other year or at
700 hours of operation. When regreasing, all old
grease, grass and dirt must be removed from the entire
partition line between the chassis halves. Always use a
silicone-free grease, for example original grease 535
14 12-01 or 535 14 12-02.
7.4 Service schedule
The table below contains a checklist of points and
actions to be taken when servicing the Automower.
When faults or a need of cleaning are discovered, this
must be rectified before the mower is used again.
Table 14: Service diagram 220 AC, 230 ACX and Solar Hybrid
No. Check/Action For
information,
see:
Replaced parts
1.
Carefully clean the lead-throughs in
the body, primarily the charging
cable (535 13 73-01) to ensure that
the rubber seals fit correctly.
2.
Check the bearings, bearing cage
and hub in the skid plate
(535 07 59-01). Clean between the
skid plate and blade disc
(535 12 63-01) as well as between
the blade disc and the rubber
bellows (535 12 23-01).
page 114
