English - 53
3. INSTALLATION
3.8 Incline conditions
The incline of a working area can be expressed in
different ways. In table 5 the relation between the
different ways of expressing an incline in per cent,
height-length ratio and in degrees are presented.
3.9 Even mowing result on complex working areas
Automower 220 AC, 230 ACX and Solar Hybrid are
equipped with setting options to assure an even
mowing result on complex working areas too. The
settings are made on the Exit angles (3-1) and Follow
loop out (3-2-1) functions. By not adapting these
settings, the area close to the charging station would
be mown more than areas situated further away that
are accessed via narrow passages. See 3.10
Installation examples, page 54 for examples of the
settings.
The garden can be divided into zones if the mowing
result is uneven in an installation for Automower 210
C. This is done with the help of the boundary wire, see
the figure on the right. When the mower is placed in
zone 1, it will not mow in zone 2 and vice versa Move
the mower between the zones to maintain an even
mowing results.
Table 5: Incline conditions
Per cent (%) Height – length ratio (1:X) Degrees (°)
10 1:10 6
20 1:5 11
30 1:3.3 17
35 1:2.9 19
40 1:2.5 22
3012-787
30 cm (12”)
zone 1
zone 2
