228 Powermax125 Service Manual 808070
9 – Power Supply Component Replacement
Figure 86
1
2
3
456
1 Rear panel
2 Straight push-to-connect fitting
3 90° push-to-connect fitting
4 Long gas tube
5 Solenoid valve
6 Short gas tube
