Hypertherm Powermax 125 Service Manual

82 Powermax125 Service Manual 808070
6 – Machine Torch Setup
125 A shielded cutting – stainless steel
Air flow rate – slpm/scfh
Hot 260 / 550
Cold 345 / 730
Metric
Material
Thickness
Torch-to-Work
Distance
Initial Pierce Height
Pierce
Delay Time
Best Quality Settings Production Settings
Cut Speed Voltage Cut Speed Voltage
mm mm mm % seconds mm/min volts mm/min volts
6
4.6
9.2 200 0.5
5910 156 7690 157
8 4060 157 5550 157
10 2540 159 3700 157
12 2170 163 2710 157
16
11.5 250
0.7 1140 165 1460 162
20 1.2 940 167 1030 163
25
Edge Start
1.0
540 172 760 166
30 510 173 610 166
32 1.1 400 177 600 169
35
1.2
320 180 450 173
40 180 185 210 179
English
Material
Thickness
Torch-to-Work
Distance
Initial Pierce Height
Pierce
Delay Time
Best Quality Settings Production Settings
Cut Speed Voltage Cut Speed Voltage
inches inches inches % seconds ipm volts ipm volts
1/4
0.18
0.36 200 0.5
220 156 288 157
3/8 104 158 154 157
1/2 78 163 98 158
5/8
0.45 250
0.7 45 165 58 162
3/4 1.2 40 167 43 163
7/8
Edge Start
0.8 30 168 35 164
1 1.0 20 173 29 166
1-1/4 1.1 16 177 24 169
1-1/2 1.2 9 183 12 177
