Hypertherm SYNC Powermax 85 User Manual

Install and Set Up the Plasma Power Supply
2
28 810470 Operator Manual Powermax65/85/105 SYNC
Powermax105 SYNC
Rated open-circuit voltage (U
0
)
200 V – 600 V CSA 300 VDC
230 V – 400 V CE 288 VDC
380 V CCC 286 VDC
400 V CE 286 VDC
Output characteristic*Drooping
Rated output current (I
2
) 30 A – 105 A
Rated output voltage (U
2
) 160 VDC
Duty cycle at 40°C (104°F)**
200 V – 600 V CSA 80% at 105 A, 480 V – 600 V, 3-phase
70% at 105 A 240 V, 3-phase
54% at 105 A 208 V, 3-phase
50% at 105 A, 200 V, 3-phase
100% at 94 A, 480 V – 600 V, 3-phase
100% at 88 A, 240 V, 3-phase
100% at 77 A, 208 V, 3-phase
100% at 74 A, 200 V, 3-phase
230 V – 400 V CE 80% at 105 A, 400 V, 3-phase
70% at 105 A, 230 V, 3-phase
100% at 94 A, 400 V, 3-phase
100% at 88 A, 230 V, 3-phase
380 V CCC 80% at 105 A, 380 V, 3-phase
100% at 94 A, 380 V, 3-phase
400 V CE 80% at 105 A, 400 V, 3-phase
100% at 94 A, 400 V, 3-phase
Operating temperature -10°C to 40°C (14°F to 104°F)
Storage temperature -25°C to 55°C (-13°F to 131°F)
Power factor
200 V – 600 V CSA, 3-phase 0.94 – 0.77
230 V – 400 V CE, 3-phase 0.94 – 0.92
380 V CCC, 3-phase 0.94
400 V CE, 3-phase 0.94
Idle state power consumption (CE systems)
230 V – 400 V CE
400 V CE
40 W
27 W
