N700E INSTRUCTION MANUAL
1-3
1.3 N700E Specification
1.3.1 230V Class Specification
Inverter Model
Max Applicable
Motor
(4P,kW(HP))
(Note1)
Rated Capacity
(kVA)
Rated Output
Current (A)
Weight
(lbs)
HD
ND
HD
ND
HD
ND
200V
240V
200V
240V
055LF/075LFP
5.5(7.5)
7.5(10)
8.3
10.0
10.4
12.5
24
30
9.26
075LF/110LFP
7.5(10)
11(15)
11.1
13.3
15.2
18.2
32
44
9.92
110LF/150LFP
11(15)
15(20)
15.6
18.7
20.0
24.1
45
50
9.92
150LF/185LFP
15(20)
18.5(25)
22.2
26.6
25.2
30.3
64
73
14.33
185LF/220LFP
18.5(25)
22(30)
26.3
31.6
29.4
35.3
76
85
16.53
220LF
22(30)
-
31.2
37.4
-
-
90
-
17.64
Rated Input Voltage
Three Phase 200 ~ 240 V +/- 10 %, 50/60 Hz +/- 5%
Rated Output Voltage
(Note2)
Three Phase 200 ~ 240 V (Corresponding to Input Voltage)
Protection Design
IP20
Table 1-2: 230V Class N700E 055LF ~ 220LF Specification Summary
Inverter Model
Max Applicable
Motor
(4P,kW(HP))
(Note1)
Rated Capacity
(kVA)
Rated Output
Current (A)
Weight
(lbs)
HD
ND
HD
ND
HD
ND
200V
240V
200V
240V
300LF/370LFP
30(40)
37(50)
39
47
48
58
114
140
53.00
370LF/450LFP
37(50)
45(60)
48
58
59
71
140
170
75.53
450LF/550LFP
45(60)
55(75)
59
71
71
85
170
205
75.53
550LF/750LFP
55(75)
75(100)
73
88
90
108
211
261
99.38
750LF/900LFP
75(100)
90(125)
87
104
107
129
261
310
101.50
Rated Input Voltage
Three Phase 200 ~ 240 V +/- 10 %, 50/60 Hz +/- 5%
Rated Output Voltage
(Note2)
Three Phase 200 ~ 240 V (Corresponding to Input Voltage)
Protection Design
IP00
Table 1-3: 230V Class N700E: 300LF ~ 750LF Specification Summary
