N700E INSTRUCTION MANUAL
3-10
3.1.5 Expanded Function Mode of C Group
Code
Name
Edit
Range
Unit
Res
Default
Input Terminal Function
C01
Intelligent Input Terminal 1
X
0 : Forward run command(FW)
1 : Reverse run command(RV)
2 : Multi-speed command 1(CF1)
3 : Multi-speed command 2(CF2)
4 : Multi-speed command 3(CF3)
5 : Multi-speed command 4(CF4)
6 : Jogging operation command(JG)
8 : 2-stage accel/decel (2CH)
9 : Free-run stop command(FRS)
10 : External trip(EXT)
11 : Unattended start protection(USP)
12 : Software lock function(SFT)
13 : Analog input current/voltage
selection(AT)
14 : Reset(RS)
15 : Start(STA)
16 : Keep(STP)
17 : Forward/reverse(F/R)
18 : Remote control UP(UP)
19 : Remote control DOWN(DOWN)
20 : Local Keypad Override (O/R)
21 : Local Terminal Input Override (T/R)
22 : PID Integral Reset(PIDIR)
23 : PID Disabled(PIDD)
24 : Freq. Override(F.O)
25 : Reset Override(R.O)
26 : External trip2(EXT2)
27 : External trip3(EXT3)
28 : External trip4(EXT4)
29 : External trip5(EXT5)
30 : External trip6(EXT6)
31: UP/DOWN Initial Value Clear
-
-
0
C02
Intelligent Input Terminal 2
X
-
-
1
C03
Intelligent Input Terminal 3
X
-
-
2
C04
Intelligent Input Terminal 4
X
-
-
3
C05
Intelligent Input Terminal 5
X
-
-
13
C06
Intelligent Input Terminal 6
X
-
-
25
Input Terminal Status
C07
Input Terminal 1 Mode
X
0: Normally Open [NO]
1: Normally Closed [NC]
-
-
0
C08
Input Terminal 2 Mode
X
0: Normally Open [NO]
1: Normally Closed [NC]
-
-
0
C09
Input Terminal 3 Mode
X
0: Normally Open [NO]
1: Normally Closed [NC]
-
-
0
C10
Input Terminal 4 Mode
X
0: Normally Open [NO]
1: Normally Closed [NC]
-
-
0
C11
Input Terminal 5 Mode
X
0: Normally Open [NO]
1: Normally Closed [NC]
-
-
0
C12
Input Terminal 6 Mode
X
0: Normally Open [NO]
1: Normally Closed [NC]
-
-
0
