3.1.8 Expanded Function Mode of U Group
Code
Name
Edit
Range
Unit
Res
Default
User Parameters
A01
Frequency Setpoint Source
X
0: Keypad Potentiometer
1: Terminal
2: Keypad Up / Down Keys
3: RJ45 Connector
(Except 300LF~750LF)
4: RXP, RXN Terminal
5: Fieldbus (option)
-
-
0
A02
Run Source
X
0: Keypad
1: Input Terminal
2: RJ45 Connector
(Except 300LF~750LF)
3: RXP, RXN Terminal
4: Fieldbus (option)
-
-
0
F01
Output Frequency Setpoint
O
0.00 to 400.00
0.00 to 300.00
for Sensorless Vector Control
Hz
0.01
--
F02
Acceleration Time 1
O
0.1 to 3000
Sec
0.1
30.0
F03
Deceleration Time 1
O
0.1 to 3000
Sec
0.1
30.0
A53
Motor Input Voltage
X
230V class inverter settings:
200/220/230/240
460V class inverter settings:
380/400/415/440/460/480
-
-
LF
230V
HF
460V
H03
Motor Capacity
X
3L(3 HP)
5L(5 HP)
7.5L(7.5 HP)
10L(10 HP)
15L(15 HP)
20L(20 HP)
25L(25 HP)
30L(30 HP)
40L(40 HP)
50L(50 HP)
60L(60 HP)
75L(75 HP)
100L(100 HP)
125L(125 HP)
3H(3 HP)
5H(5 HP)
7.5H(7.5 HP)
10H(10 HP)
15H(15 HP)
20H (20 HP)
25H (25 HP)
30H (30 HP)
40H (40 HP)
50H (50 HP)
60H (60 HP)
75H (75 HP)
100H (100 HP)
125H (125 HP)
150H (150 HP)
200H (200 HP)
250H (250 HP)
275H (275 HP)*
300H (300 HP)
350H (350 HP)*
400H (400 HP)
425H (425 HP)*
450H (450 HP)
500H (500 HP)
-
-
-
H05
Motor Rated Current
X
0.1 to 800.0
A
0.1
-
A03
Base Frequency Setpoint
X
0.00 to A04 (Max Frequency)
Hz
0.01
60.00
A04
Maximum Frequency
Setpoint
X
A03 to 400.00
(if A31=2): A03 to 300.00
Hz
0.01
60.00
* This Group is a collection of frequently used parameters
