N700E INSTRUCTION MANUAL
1-14
1.5.1 N700E-055LF/075LFP, N700E-075LF/110LFP, N700E-110LF/150LFP,
N700E-055HF/075HFP,N700E-075HF/110HFP, N700E-110HF/150HFP
8.27 inch [W]
7.44 inch [W1]
9.69 inch [H1]
10.83 inch [H]
6.61 inch [D]
2-Ф 0.28 inch
2-0.28 inch
0.28
0.87
Figure 1-8: Physical Dimension Specific to 055LF~110LF, 055HF~110HF
1.5.2 N700E-150LF/185LFP, N700E-185LF/220LFP, N700E-220LF,
N700E-150HF/185HFP, N700E-185HF/220HFP, N700E-220HF/300HFP
9.84 inch [W]
15.35 inch [H]
14.8 inch [H1]
7.4 inch [D]
9.02 inch [W1]
2-Ф 0.28 inch
2-0.28 inch
0.28 0.28
Figure 1-9: Physical Dimension Specific to 150LF~220LF, 185HF~220HF
